Feature

Model

CBD20

Configuration No.

150G

Load capacity

2000 kg

Load center

600 mm

Wheel base

1418 mm

Operating type

Walkie

Wheels

Wheels type (Front/Rear)

PU

Driving wheel /Balance wheel/Bearing wheel

1/2/4

Driving wheel size

Φ248×75 mm

Balance wheel size

Φ90×48 mm

Bearing wheel size

Φ80×80 mm

Dimension

Min.fork lowered height

85 mm

Max.fork lifting height

205 mm

Max.lifting height

120mm

Outside width between forks

550/600/650/685 mm

Inside width between forks

210/260/310/345 mm

Fork length

1150/1200 mm

Fork width

170 mm

Fork thickness

75 mm

Overall length

1830 mm

Overall width

726 mm

Overall height(With handle)

1465 mm

Overall height(Without handle)

850 mm

Min.Turning radius

1587 mm

Min.Aisle width for pallets 800×1200

1840 mm

Min.Aisle width for pallets 1000x1200

1875mm

Performance

Travel speed,laden/unladen

3.5/4 km/h

Lift speed,laden/unladen

30/35 mm/s

Lowering speed,laden/unladen

40/35 mm/s

Gradeability,laden/unladen

5/7 %

Electrical configuration

Drive motor/Lift motor/Steering motor

AC0.95/DC1.2 KW

Battery voltage / capacity

24/170 (Maintenance - free/VRLA) V/Ah

Brake

Electromagnetic/Regenerative

Controller

CURTIS

Weight

Battery weight

122 kg

Service weight with battery

532 kg
