Feature

Model

CBD20

Configuration No.

150

Load capacity

2000kg

Wheel base

600mm

Load center

1390mm

Operating type

Walkie

Wheels

Wheels type

PU

Driving wheel /Balance wheel/Bearing wheel

1/1/4

Driving wheel size

Φ248×75mm

Balance wheel size

Φ115×55mm

Bearing wheel size

Φ84×80mm

Dimension

Min.fork lowered height

85mm

Max.fork lifting height

195mm

Max.lifting height

110mm

Outside width between forks

540/600/650/685mm

Inside width between forks

200/260/330/345mm

Fork length

1150/1200mm

Fork width

170mm

Fork thickness

75mm

Overall length

1750mm

Overall width

720mm

Overall height(With handle)

1385mm

Overall height(Without handle)

850mm

Min.Turning radius

1575mm

Min.Aisle width for pallets 800×1200

1900mm

Min.Aisle width for pallets 1000×1200

1940mm

Performance

Travel speed,Laden/unladen

3.5/4 km/h

Lift speed,laden/unladen

30/35 mm/s

Lowering speed,laden/unladen

40/35 mm/s

Gradeability,laden/unladen

6/16 %

Electrical configuration

Drive/Lift/Steering motor

AC1.5/DC1.2/DC0.15 KW

Battery voltage/capacity

24/210 V/Ah

Brake

Electromagnetic/Regenerative

Controller

ZAPI

Weight

Battery weight

192kg

Service weight with battery

605kg
