Feature

Model

Operating type

Waikle

Load capacity

Load center

600mm

Wheel base

Service weight with battery

Controller

HELI（Option:CURTIS）

Wheels

Wheels type

PU

Wheel quantity

Driving wheel/Balance whee/Bearing wheel

1/1/4

Driving wheel size

Φ252mmX60mm

Bearing wheel size

Φ84mmX70mm

Balance wheel size

Φ115mmX55mml

Dimension

Standard lift height

2000/2500/3000/3300mm

Max extend height

2515/3015/3515/3815mm

Mast lowered height

1560/1810/2060/2210mm

Lowered fork height

90mm

Overall length

Overall width

790mm

Fork size(length/width/thickness)

1150/185/55mm

Outside width between forks

550/600/650/685mm

Min.Turning radius

Min.Aisle width for pallets 800x1200

Min.Aisle width for pallets 1000x1200

Performance

Travel speed,laden/unladen

Lift speed,laden/unladen

120/200/ mm/s

Lowering speed,laden/unladen

Gradeability,laden/unladen

5/7 %

Electrical configuration

Drive motor / Lift motor

Battery voltage

24V

Battery capacity

85（or 105）Ah

Battery weight

48kg

Charger specification

24V/10A

Others

Sound level

≤69

Steering type

mechanicalsteering
