Feature |
Model | CBD15-170HA |
Operating type | Walkie |
Load capacity | 1500kg |
Load center | 600mm |
Wheel base | 1325mm |
Wheels |
Wheels type | PU |
Wheel quantity no.(x=driven)front/rear | 1x+2/4 |
Driving wheel size | Φ210mmX70mm |
Bearing wheel size | Φ84mmX70mm |
Balance wheel size | Φ70mmX30mm (Optional) |
Dimension |
Min.fork lowered height | 85mm |
Max.fork lifting height | 205mm |
Max.lifting height | 120mm |
Qutside width between forks | 550mm/685mm |
Inside width between forks | 230mm/365mm |
Fork length | 1150mm |
Fork width | 160mm |
Fork thickness | 55mm |
Overall length | 1730mm |
Overall width | 698mm |
Overall height(With handle) | 1225mm |
Overall height(Without handle) | 648mm |
Min.Turning radius | 1510mm |
Min.Aisle width for pallets 800x1200 | 1835mm |
Min.Aisle width for pallets 1000x1200 | 1865mm |
Performance |
Travel speed,laden/unladen | 4/4.5km/h |
Lift speed,laden/unladen | 35/40 mm/s |
Lowering speed,laden/unladen | 65/60 mm/s |
Gradeability,laden/unladen | 10/20 % |
Service brake type | Electric |
Electrical configuration |
Traction motor rating at S2 60 min | DC 0.63 kw |
Lift motor rating at S3 15% | DC 0.8 kw |
Battery voltage / capacity | 2X12/85 V/AH |
Charger specification | 24/10 V/A |
Weight |
Battery weight(±5%) | 2X24kg |
Service weight with battery | 232kg |
Others |
Sound level | ≤75dB(A) |
Steering type | Mechanical |
Drive control type | DC |
