Feature |
Model | CBD15-190Li | CBD20-190Li |
Operating type | Walkie | Walkie |
Load capacity | 1500kg | 2000kg |
Load center | 600mm |
Wheel base | 916/1166/1216(mm) | 980/1230/1280(mm) |
Wheels |
Wheels type | PU |
Wheel quantity Driving wheel/Balance wheel/Bearing wheel | 1/2/4 |
Driving wheel size | Φ145mmX54mm |
Bearing wheel size | Φ70mmX30mm |
Balance wheel size | Φ84mmX70mm |
Dimension |
Min.fork lowered height | 85mm |
Max.fork lifting height | 205mm |
Max.lifting height | 120mm |
Outside width between forks | 560/685(mm) |
Inside width between forks | 240/365(mm) |
Fork length | 900/1150/1200(mm) |
Fork width | 160mm |
Fork thickness | 55(mm) |
Overall length | 1400/1650/1700(mm) | 1465/1715/1765(mm) |
Overall width | 560/685(mm) |
Overall height(With Handle) | 1166mm |
Overall height(Without Handle) | 700mm |
Min.Turning radius | 1055/1305/1355(mm) | 1120/1370/1420(mm) |
Min.Aisle width for pallets 800x1200 | 1745mm | 1810mm |
Min.Aisle width for pallets 1000x1200 | 1770mm | 1835mm |
Performance |
Travel speed,laden/unladen | 4.5/5.0km/h | 3.8/4.5km/h |
Lift speed,laden/unladen | 25/40mm/s |
Lowering speed,laden/unladen | 70/50mm/s | 50/40mm/s |
Gradeability,laden/unladen | 6/16 % |
Electrical configuration |
Drive motor/Lift motor | AC0.8/AC0.8(KWh) | AC1.0/AC1.0(KWh) |
Battery voltage/capacity | 72/8(VAh) | 72/16(VA) |
Charger specification | 72/4(VA) | 72/8(VA) |
Controller | HELI |
Weight |
Battery weight | 5.2Kg | 11Kg |
Service weight(with battery) | 118Kg | 166Kg |
Others |
Noise level | <=75dB(A) |
Steering type | Mechanical |
Driver controller type | AC |
