Feature |
Model | CBD40/45/50 |
Configuration No. | 510 | 520 |
Load capacity | 4000/4500/5000 kg |
Load center | Double pallet | Single pallet |
Wheel base | 2084 mm | 1569 mm |
Operating type | Rider |
Wheels |
Wheels type (Front/Rear) | PU |
Wheel quantity (Driving/Balance/Bearing wheel) | 1/4/2(4) |
Driving wheel size | Φ300×120 mm |
Balance wheel size | Φ115×55 mm |
Bearing wheel size | Φ82×152 mm |
Dimension |
Min.fork lowered height | 85 mm |
Max.fork lifting height | 230 mm |
Max.lifting height | 145 mm |
Outside width between forks | 680 mm |
Inside width between forks | 180 mm | 220 mm |
Fork length | 2432 mm | 1212/1365/1517 mm |
Fork width | 250 mm | 230 mm |
Fork thickness | 60 |
Overall length | 3605 mm | 2374 mm |
Overall width | 930 mm |
Overall height(With handle) | 1536 mm |
Overall height(Without handle) | 1280 mm |
Min.Turning radius | 2708 mm | 2190 mm |
Min.Aisle width for pallets 1200×1200 | 3650 mm | 2536 mm |
Performance |
Travel speed,laden/unladen | 8/8 km/h |
Lift speed,laden/unladen | 35/50 mm/s |
Lowering speed,laden/unladen | 35/30 mm/s |
Gradeability,laden/unladen | 3/6 % |
Electrical configuration |
Drive motor/Lift motor/Steering motor | AC4.2/DC2.2/DC0.15 KW |
Battery voltage/capacity | 24/360 V/Ah |
Brake | Electromagnetic/Regenerative |
Controller | ZAPI |
Weight |
Battery weight | 302 kg |
Service weight with battery | 1190 kg | 1063 kg |
