Feature |
Model | CBD20 |
Configuration No. | 490 |
Load capacity | 2000 kg |
Load center | 600 mm |
Wheel base | 1569 mm |
Operating type | Stand on |
Wheels |
Wheels type (Front/Rear) | PU |
Wheel quantity (Driving/Balance/Bearing wheel) | 1/2/4 |
Driving wheel size | Φ248×75 mm |
Balance wheel size | Φ115×55 mm |
Bearing wheel size | Φ84×80 mm |
Dimension |
Min.fork lowered height | 85 mm |
Max.fork lifting height | 205 mm |
Max.lifting height | 120 mm |
Outside width between forks | 550/600/650/685 mm |
Inside width between forks | 210/260/310/345 mm |
Fork length | 1150/1200 mm |
Fork width | 170 mm |
Fork thickness | 75 mm |
Overall length | 2465 mm |
Overall width | 790 mm |
Overall height(With handle) | 1172 mm |
Overall height(Without handle) | -- |
Min.Turning radius | 2278 mm |
Min.Aisle width for pallets 800×1200 | 2568 mm |
Min.Aisle width for pallets 1000×1200 | 2589 mm |
Performance |
Travel speed,laden/unladen | 7/7 km/h | 10/11km/h (for optional) |
Lift speed,laden/unladen | 30/35 mm/s |
Lowering speed,laden/unladen | 40/35 mm/s |
Gradeability,laden/unladen | 10/15 % |
Electrical configuration |
Drive motor/Lift motor/Steering motor | AC3/DC1.2/DC0.3 KW |
Brake | Electromagnetic/Regenerative |
Battery | Lead-acid battery | Lithium battery(optional) |
Battery voltage/capacity | 24/280 V/Ah | 24/200 V/Ah |
Controller | ZAPI | ZAPI |
Battery weight | 243 kg | 104 kg |
Service weight(with battery) | 840 kg | 680 kg |
