Feature

Model

CBD20/25

Configuration No.

460P

Load capacity

2000/2500/kg

Wheel base

1526mm

Operating type

Stand on

Wheels

Wheels type

PU

Wheel quantity Driving wheel/Balance wheel / Bearing wheel

1/0/2

Driving wheel size

Φ248mmX75mm

Bearing wheel size

Φ235mmX85mm

Dimension

Min.fork lowered height

50mm

Overall length

2250mm/2670mm

Overall width

860mm

Overall height(With handle)

1455mm

Min.Turning radius

1656mm/2170mm

Performance

Travel speed,laden/unladen

6/6km/h

Gradeability,laden/unladen

6/16 %

Electrical configuration

Driver motor / Lift motor / Steering motor

AC1.5 /DC0.15

Battery voltage/capacity

24/270 V/Ah

Charger specification

24/50 V/A

Controlller

ZAPI

Weight

Battery weight

247kg

Service weight(with battery)

780kg

Others

Sound level

≤75

Steering type

Electronic

Drive control type

AC
