Feature
|
Model
| CBD15
|
Configuration No.
| 610
|
Load capacity
| 1500kg
|
Load center
| 600mm
|
Wheel base
| 1234mm
|
Operating type
| Walkie
|
Wheels
|
Wheels type
| PU
|
Wheel quantity Driving wheel/Balance wheel /Bearing wheel
| 1/2/4
|
Driving wheel size
| Φ252mmX67mm
|
Bearing wheel size
| Φ99.5mmX40mm
|
Balance wheel size
| Φ84mmX70mm
|
Dimension
|
Min.fork lowered height
| 85mm
|
Max.fork lifting height
| 205mm
|
Max.lifting height
| 120mm
|
Qutside width between forks
| 550mm/600mm/650mm/685mm
|
Inside width between forks
| 220mm/280mm/330mm/365mm
|
Fork length
| 1150mm/1200mm
|
Fork width
| 160mm
|
Fork thickness
| 75mm
|
Overall length
| 1630mm
|
Overall width
| 724mm
|
Overall height(With handle)
| 1220mm
|
Overall height(Without handle)
| 685mm
|
Min.Turning radius
| 1400mm
|
Min.Aisle width for pallets 800x1200
| 1817mm
|
Min.Aisle width for pallets 1000x1200
| 1858mm
|
Performance
|
Travel speed,laden/unladen
| 3.5/4 km/h
|
Lift speed,laden/unladen
| 35/40 mm/s
|
Lowering speed,laden/unladen
| 45/40 mm/s
|
Gradeability,laden/unladen
| 5/7 %
|
Electrical configuration
|
Drive motor/Lift motor /Steering motor
| DC0.63/DC0.8 kw
|
Battery voltage/capacity
| 24/85 V
|
Brake
| Electromagnetic /Regenerative
|
Controller
| HELI(CURTIS)
|
Weight
|
Battery weight(±5%)
| 48kg
|
Service weight with battery
| 278
|
